型号 | 激 振力(N) | 额定转速 (Rpm) | 额定功率 (Kw) | 电流 (A) | 电压 (V) | 安装尺寸(mm) | 外形尺寸(mm) | 重量 (Kg) | |||||||
A | B | H | K | AB | BB | HD | G | L | |||||||
YZU-1-2 | 1000 | 2860 | 0.09 | 0.42 | 380 | 130 | 80 | 80 | 12 | 170 | 140 | 154 | 16 | 260 | 13 |
YZU-1.5-2 | 1500 | 2860 | 0.15 | 0.5 | 130 | 80 | 80 | 12 | 170 | 140 | 154 | 16 | 260 | 13.5 | |
YZU-2-2 | 2000 | 2860 | 0.18 | 0.54 | 130 | 80 | 80 | 12 | 170 | 140 | 154 | 16 | 260 | 14 | |
YZU-2.5-2 | 2500 | 2860 | 0.20 | 0.55 | 130 | 80 | 80 | 12 | 170 | 140 | 154 | 16 | 260 | 19 | |
YZU-3-2 | 3000 | 2860 | 0.25 | 0.6 | 150 | 90 | 90 | 14 | 185 | 150 | 172 | 18 | 280 | 20 | |
YZU-5-2 | 5000 | 2860 | 0.37 | 0.9 | 150 | 90 | 90 | 14 | 185 | 150 | 172 | 18 | 280 | 21 | |
YZU-8-2 | 800 | 2860 | 0.75 | 1.75 | 180 | 110 | 110 | 18 | 220 | 180 | 230 | 18 | 340 | 36 | |
YZU-10-2 | 10000 | 2860 | 0.75 | 1.75 | 180 | 110 | 110 | 18 | 220 | 180 | 230 | 18 | 340 | 37 | |
YZU-15-2 | 15000 | 2860 | 1.1 | 2.3 | 220 | 140 | 120 | 22 | 270 | 225 | 260 | 25 | 415 | 47 | |
YZU-20-2 | 20000 | 2860 | 1.5 | 3.1 | 260 | 150 | 140 | 26 | 320 | 280 | 310 | 28 | 445 | 80 | |
YZU-30-2 | 30000 | 2860 | 1.5 | 3.6 | 310 | 170 | 160 | 33 | 380 | 285 | 356 | 30 | 536 | 130 | |
YZU-50-2 | 50000 | 2860 | 2.2 | 5.1 | 350 | 220 | 190 | 33 | 440 | 350 | 410 | 35 | 608 | 180 | |
YZU-1.5-4 | 1500 | 1440 | 0.15 | 0.5 | 130 | 80 | 80 | 12 | 170 | 140 | 154 | 16 | 260 | 15 | |
YZU-2-4 | 2000 | 1440 | 0.15 | 0.5 | 130 | 80 | 80 | 12 | 170 | 140 | 154 | 16 | 260 | 15.5 | |
YZU-2.5-4 | 2500 | 1440 | 0.18 | 0.6 | 150 | 90 | 90 | 14 | 185 | 150 | 172 | 18 | 280 | 21 | |
YZU-3-4 | 3000 | 1440 | 0.18 | 0.6 | 150 | 90 | 90 | 14 | 185 | 150 | 172 | 18 | 280 | 23 | |
YZU-5-4 | 5000 | 1440 | 0.25 | 0.75 | 180 | 110 | 112 | 18 | 220 | 180 | 230 | 18 | 340 | 37 | |
YZU-8-4 | 8000 | 1440 | 0.55 | 1.5 | 220 | 140 | 120 | 22 | 265 | 225 | 266 | 25 | 415 | 48 | |
YZU-10-4 | 10000 | 1440 | 0.55 | 1.5 | 220 | 140 | 120 | 22 | 265 | 225 | 266 | 25 | 415 | 49 | |
YZU-15-4 | 15000 | 1440 | 0.75 | 1.9 | 260 | 150 | 140 | 26 | 310 | 245 | 303 | 28 | 450 | 77 | |
YZU-20-4 | 20000 | 1440 | 1.1 | 2.6 | 260 | 150 | 140 | 26 | 310 | 245 | 303 | 28 | 450 | 82 | |
YZU-30-4 | 30000 | 1440 | 1.5 | 3.6 | 310 | 170 | 160 | 33 | 380 | 285 | 356 | 30 | 536 | 130 | |
YZU-50-4 | 50000 | 1440 | 2.2 | 5.1 | 350 | 220 | 190 | 33 | 440 | 350 | 410 | 35 | 608 | 180 | |
YZU-75-4 | 75000 | 1440 | 3.7 | 8.4 | 380 | 250 | 220 | 33 (45) | 446 | 340 | 425 | 40 | 615 | 230 | |
YZU-100-4 | 100000 | 1440 | 5.5 | 11 | 440 | 280 | 240 | 36 (52) | 530 | 410 | 475 | 45 | 710 | 435 | |
YZU-140-4 | 140000 | 1440 | 7.5 | 15 | 480 | 280 | 260 | 6-45 | 575 | 498 | 560 | 60 | 832 | 700 | |
YZU-3-6 | 3000 | 960 | 0.25 | 0.84 | 180 | 110 | 112 | 18 | 220 | 180 | 220 | 18 | 340 | 39 | |
YZU-5-6 | 5000 | 960 | 0.37 | 1.2 | 220 | 140 | 120 | 22 | 265 | 225 | 266 | 25 | 415 | 50 | |
YZU-8-6 | 8000 | 960 | 0.55 | 1.5 | 220 | 140 | 120 | 22 | 265 | 225 | 266 | 25 | 415 | 67 | |
YZU-10-6 | 10000 | 960 | 0.75 | 2.2 | 260 | 150 | 140 | 26 | 310 | 245 | 305 | 28 | 450 | 83 | |
YZU-15-6 | 15000 | 960 | 1.1 | 3.1 | 310 | 170 | 160 | 33 | 380 | 285 | 356 | 30 | 536 | 136 | |
YZU-20-6 | 20000 | 960 | 1.5 | 4.0 | 310 | 170 | 160 | 33 | 380 | 285 | 356 | 30 | 536 | 140 | |
YZU-30-6 | 30000 | 960 | 2.2 | 5.6 | 350 | 220 | 190 | 33 | 440 | 350 | 410 | 30 | 608 | 190 | |
YZU-40-6 | 40000 | 960 | 3 | 7.2 | 350 | 220 | 190 | 33 | 440 | 350 | 410 | 30 | 608 | 210 | |
YZU-50-6 | 50000 | 960 | 3.7 | 8.4 | 380 | 250 | 220 | 33 (45) | 446 | 340 | 425 | 40 | 615 | 230 | |
YZU-75-6 | 75000 | 960 | 5.5 | 11 | 440 | 280 | 240 | 35 (52) | 530 | 410 | 475 | 45 | 710 | 435 | |
YZU-100-6 | 100000 | 960 | 7.5 | 15 | 480 | 280 | 260 | 6-45 | 575 | 498 | 560 | 60 | 832 | 610 | |
YZU-140-6 | 140000 | 960 | 10 | 22 | 480 | 280 | 275 | 6-45 | 575 | 498 | 575 | 75 | 880 | 700 | |
YZU-5-8 | 5000 | 720 | 0.75 | 2.2 | 260 | 150 | 140 | 26 | 310 | 245 | 305 | 28 | 450 | 83 | |
YZU-10-8 | 10000 | 720 | 0.75 | 2.4 | 310 | 170 | 160 | 33 | 380 | 285 | 356 | 30 | 536 | 145 | |
YZU-20-8 | 20000 | 720 | 1.5 | 4.3 | 350 | 220 | 190 | 33 | 440 | 350 | 410 | 35 | 608 | 210 | |
YZU-30-8 | 30000 | 720 | 3.7 | 8.4 | 380 | 250 | 220 | 33 | 446 | 340 | 425 | 40 | 615 | 230 | |
YZU-50-8 | 50000 | 720 | 5.5 | 11 | 440 | 280 | 240 | 35 | 530 | 410 | 475 | 45 | 710 | 435 | |
YZU-75-8 | 75000 | 720 | 7.5 | 15 | 480 | 280 | 260 | 6-45 | 575 | 498 | 560 | 60 | 832 | 610 | |
YZU-100-8 | 100000 | 720 | 10 | 22 | 480 | 280 | 275 | 6-45 | 575 | 498 | 575 | 75 | 880 | 700 |
振动源三相异步电动机为各类振动机械通用激振源。如振动给料机,振动输送机、振动烘干机、振动放矿机、振动落砂机、振动筛分机、料仓的振动防闭塞等。可广泛应用于电力、建材、粮食、煤炭、矿山、冶金、化工、轻工、铸造、铁道、水泥、港口等待业,深受广大用户欢迎。
环境温度:不超过40oC 海 拔:不超过1000米
电源电压:380伏 电源频率:50赫兹
防护等级:IP54 IP55 接 法:Y 或 Δ
绝缘等级:B、F 工作方法:S1(连续)
